Welded T Shape Stainless Steel Beam Profile 316L Structural Support Section

Welded T Shape Stainless Steel Beam Profile is a structural T section fabricated by welding stainless steel plate or strip in grade 316L, for support grilles, machinery frames and corrosive industrial environments. The T section places material in the flange and web to resist bending in the strong axis, and its flat faces make it easy to bolt, weld and connect. The 316L grade contains 2 to 3 percent molybdenum, giving the profile excellent resistance to pitting and crevice corrosion in chloride, chemical and marine environments where carbon steel would quickly deteriorate.

Because the section is welded rather than rolled, its web height, flange width and thickness can be produced to almost any practical size, allowing designers to match the profile precisely to the load case and connection detail. The low carbon content of 316L keeps the heat affected zone resistant to intergranular corrosion after welding. Finished profiles are pickled, annealed or polished, inspected dimensionally, and supplied with a mill test certificate for full traceability.

• 316L Corrosion Resistance: Molybdenum bearing 316L resists pitting, crevice and chloride corrosion, making the profile suitable for marine, chemical and food environments.
• T Section Strength: The T cross section concentrates steel in the flange and web, providing strong bending resistance in the major axis for supports and frames.
• Welded Fabrication: Produced by welding plate or strip, so web height, flange width and thickness can be customised to the exact project requirement.
• Low Carbon Weldability: A carbon content capped at 0.03 percent keeps the heat affected zone resistant to intergranular corrosion after fabrication welding.
• Machinable and Connectable: Flat flanges and web make drilling, bolting and welding straightforward for grilles, brackets and machinery frames.
• Certified and Traceable: Produced under ISO 9001 management with SGS inspection and a mill test certificate covering grade, dimensions and mechanical properties.

Welded T shape stainless steel beams are used for support grilles and grating frames, machinery and equipment frames, conveyor and platform supports, and structural brackets in chemical plants, desalination facilities, food and pharmaceutical processing, and marine and offshore installations. The corrosion resistance of 316L makes the profile ideal where washdown, salt spray or aggressive chemicals are present, while its weldability and machinability suit custom fabrication of one off and series components. The flat, uniform surfaces also make it easy to clean and maintain in hygienic environments.

Each stainless T profile is produced under an ISO 9001 certified quality management system from certified 316L stainless steel. Chemical composition, dimensions and mechanical properties are verified before shipment, and every order is supplied with a mill test certificate for full traceability. We provide SGS third party inspection, dimensional reports and pre-shipment photographs on request. Cutting, bevelling, drilling, pickling and polishing services are available so profiles arrive ready for fabrication.
